Image Intensifier Tube: Gen 2+ "Level 1"
Magnification: 5.6x
Lens System: 145 mm; F/1.8
FOV: 7°
Warning: California's Proposition 65
Image Intensifier Tube
Gen 2+ "Level 1"
Resolution
51-64 lp/mm
Field of view cleanness by zone
Gen 2 IIT NL1 is the highest resolution and the cleanest offered by AGM. There are practically no visible spots in Zone 1.
Magnification
5.6x
Lens System
145 mm; F/1.8
FOV
7°
Focus Range
25m to Infinity
Diopter Adjustment
-6 to +2 dpt
Led Indicators
Low battery; IR On; Excessive light conditions
Automatic Brightness Control
Yes
Infrared Illuminator
Detachable long-range IR illuminator
Bright Light Cut-Off
Yes
Automatic Shut-Off System
Yes
Battery Type
2 AA Alkaline or 1 Lithium (BA-5567/U)
Battery Life (Operating)
Up to 40 hours at 20°C
Operating Temperature Range
-40°C to +50°C (-40°F to +122°F)
Storage Temperature Range
-50°C to +50°C (-58°F to +122°F)
Weight
1.02 kg (2.25 lbs)
Overall Dimensions
282 × 152 × 96 mm ( 11.1 × 6.0 × 3.8 in)
Package Includes
Night Vision Binocular, Sioux850 Detachable Long-Range IR Illuminator, Lens Cloth, Soft Carrying Case
Select a row below to filter reviews.
Refresh rate: 50 Hz
Resolution: 384x288
FOV: 10.5° × 7.9°
